PC3000 with 26" Deck (PC3000-26) User’s Manual
5-10 Document ID 13-003 v 2.0
4. At the prompt (Figure 5-6), press F6 to set the position, or press F5 to cancel.
Figure 5-6: Submit Position Prompt
5. Once you have set the position, a confirmation message (Figure 5-7) is displayed for 5 seconds.
Figure 5-7: Position Set Confirmation Message
6. Repeat steps 3 – 5 for roller and mouse hole setpoints.
7. Test the unit to ensure the positions you have set are accurate.
8. To review the set positions, use the F1 and F2 keys to scroll through the HMI screens (Figure 5-8).
Figure 5-8: Roller Position
Error Messages
Error messages displayed on the HMI screen indicate possible malfunctions during operation of the
Catwalk.
Cold Hyd. Oil – Indicates the hydraulic oil is too cold to allow the system to operate. The motor can be
started, but none of the functions will operate until the tank temperature is above 23ºF (–5ºC). Make sure
the hydraulic oil tank heater breaker is turned on in the main electrical box (Figure 3-13, page 3-14). The
error cannot be cleared until the oil temperature is above 23ºF (–5ºC). If it is determined that the tank
temperature transmitter is not operating correctly, call Canrig for Service.
Hot Hyd. Oil – Indicates the hydraulic oil temperature has exceeded the upper limit of 170ºF (76ºC),
resulting in a shutdown. Make sure the cooler fan is running and the cooler is clean. The error cannot be
cleared until the oil temperature is low enough to safely operate the hydraulics.
SET POS PRESS F6
CANCEL PRESS F5
POCKET POSITION
SET!
ROLLER POSITION
7500
