Canrig PC3000 - 121300024 ASSY,VLV STACK,CARRIER

Engineering
Bill of Material
Part:
ASSY,VLV STACK,CARRIER
Drawing ID:
121300024
Rev No:
C
Item Qty Part ID
Description
Units
Description:
Eng ID:
4
Part:
121300024
01 2.00 ELL 90°, MALE 1 JIC, MALE 3/4 ORBEA H15-070220-16-12
02 1.00 ADAPTER, FEM SWV 1/2 JIC, 3/8 MALE ORBEA H15-0506-08-06
03 1.00 TRANSDUCER, PRESS, 7500 PSI, 4-20mAEA N10298
04 1.00 ADPT, FEM SWVL 1/4 JIC, MALE 1/4 NPTEA H15-2018-04-04
05 1.00 ELL 90°, MALE 1/4 JIC, MALE #5 ORBEA H15-070220-04-05
06 1.00 TEE,FEM SWV RUN 1 IN JIC, MALE 1 IN JICEA H15-070432-16-16
07 1.00 ADPT, MALE 1/2 JIC, MALE 3/8 ORBEA H15-070120-08-06
08 10.00 ADPT, MALE 1/2 JIC, MALE 5/8 ORBEA H15-070120-08-10
09 1.00 ASSY, HYD, CARRIER VLV, PVG32EA
A
Y50448
10 1.00 REDUCER, JIC 1 FEM, 1/2 MALEEA H15-070123A-16-08
11 4.00 WASHER, F, 5/16, PLAIN, TYPE A, NARROWEA FW-0312-A-N
12 4.00 LOCKWASHER, 5/16 HELICAL SPRINGEA LW-0312-HS
13 4.00 CAPSCR, HEX HD, 5/16-18UNC x 0.75, GR8EA HH-0312NC-0075-GR8
Printed:
1/31/2014
