Canrig PC3000 - 121300001 PIPE CARRIER SKATE DRIVE ASSY

Engineering
Bill of Material
Part:
PIPE CARRIER SKATE DRIVE ASSY
Drawing ID:
121300001
Rev No:
B
Item Qty Part ID
Description
Units
Description:
Eng ID:
2
Part:
121300001
01 1.00 SHAFT, SKATE DRIVEEA 161100033
02 1.00 SKATE WINCH DRUMEA 161100032
03 1.00 BUSH, 3 1/2 BORE, 7/8 x 7/16 KEYEA M10576
04 2.00 BRG FLANGEEA 161100087
05 1.00 FLOATING END SKATE MOUNTEA 161100097
06 1.00 MOUNT ENTRANCE CAPEA 161100096
07 2.00 CAP PLATEEA 141100152
08 1.00 KEY, DRUM W/ ROUNDED ENDSEA DT50202
09 2.00 FTG, GREASE, 1/8 NPT, PTF-SSEA M10533
10 1.00 SPROCKET, DOUBLE, 45 TEETH, #60 (3/4IN)EA M10512
11 1.00 BUSH, 3 1/2 BORE, 7/8 x 1/16 KEYEA M10615
12 15.00 LOCKWASHER, 1/2, HELICAL SPRINGEA LW-0500-HS
13 12.00 CAPSCR, HEX HD, 1/2-13UNC x 1.50, GR8EA HH-0500NC-0150-GR8
14 3.00 LOCKWASHER, 5/8 HELICAL SPRINGEA LW-0625-HS
15 3.00 CAPSCR, HEX HD, 5/8-11UNC x 2.50, GR8EA HH-0625NC-0250-GR8
16 8.00 LOCKWASHER, 1/4 HELICAL SPRINGEA LW-0250-HS
17 8.00 CAPSCR, HEX HD, 1/4-20UNC x 1.00, GR8EA HH-0250NC-0100-GR8
18 3.00 CAPSCR, HEX HD, 1/2-13UNC x 2.75, GR8EA HH-0500NC-0275-GR8
19 2.00 BRG, SPHER, ROL, 80mm x 140mm x 33mmEA M10495
20 2.00 RETNG RING, SPIRAL, INT, 5.62INEA M10487
2
1-REF 1.00 KEY STOCK, 7/8 x 1/2 x 2 7/8 LGEA DT50201
22 1.00 RETNG RING, SPIRAL, EXT, 3.15 INEA M10493
Printed:
1/31/2014
