Canrig PC3000 - 111100014 CATWALK,PC3000,26 IN,600 V,PCKTS FWD

Engineering
Bill of Material
Part:
CATWALK,PC3000,26IN,600V,PCKTS FWD
Drawing ID:
111100004
Rev No:
J
Item Qty Part ID
Description
Units
Description:
Eng ID:
15
Part:
111100014
01 1.00 ASSY, HYD, MOTOR & PUMP, 75HP, 575-600VEA 121100024
02 1.00 ASSY,HYD TANK,PC3000,600VEA 121100123
03 1.00 ASSY, VLV BANK, HYD, CATWALK, OUTFITTEDEA 121100037
04 1.00 ASSY, COOLER, HYD OIL, PC3000, OUTFITTEDEA 121100038
05 1.00 ASSY, VLV MANF, HYD, PRESS RED, OUTFITTEEA 121100039
06 1.00 ASSY, VLV, PROP PRESS CTRL, OUTFITTEDEA 121100040
07 2.00 ASSY, GUARD, COOLER AND HOSEEA 121100202
08 6.00 PIPERACK ARMEA 121600001
09 2.00 26 IN CATWALK PIVOTING DECKSTAIREA 131100326
10 1.00 PLATE, VERTICAL GUIDE STRIPEA 141500005
11 4.00 PAD, MOTOR MOUNTEA 141500010
12 2.00 PAD, TANK MOUNTEA 141500012
13 2.00 GUARD, CONTROL BOXEA 153100057
14 1.00 BLOCK, WHEEL, RHEA 161100018
15 1.00 BLOCK, WHEEL, LHEA 161100019
16 6.00 PIN, 1.50 x 4.25, INDEXER, PIPE STOPPEREA 161100027
17 10.00 KIT, VERT GUIDE FASTENEREA
A
Y50296
18 4.00 KIT, POCKET FASTENER LGEA
A
Y50298
19 6.00 KIT 1, LASER EYE FASTENEREA
A
Y50299
20 1.00 KIT, LASER EYE GUARDEA
A
Y50300
21 2.00 KIT, LASER EYE FASTENEREA
A
Y50301
22 1.00 KIT, REAR LASER EYE MOUNTEA
A
Y50302
23 15.00 KIT, TANK GUARD FASTENEREA
A
Y50303
24 4.00 KIT, REAR RAMP FASTENEREA
A
Y50306
25 2.00 KIT, PULLER POST FASTENEREA
A
Y50307
26 4.00 KIT, TANK ANGLE GUARD FASTENEREA
A
Y50308
27 4.00 KIT, TANK MOUNTING FASTENERSEA
A
Y50309
28 4.00 KIT, HPU CONNECTIONEA
A
Y50310
29 2.00 KIT, 4VP01 FASTENEREA
A
Y50311
30 4.00 KIT, PLC BOX MOUNTEA
A
Y50312
31 4.00 KIT, HP FILTER FASTENEREA
A
Y50313
32 2.00 KIT, PRV FASTENEREA
A
Y50314
33 4.00 KIT, COOLER MOUNTEA
A
Y50315
34 2.00 KIT 1, VALVE FASTENEREA
A
Y50316
35 2.00 KIT 2, VALVE FASTENEREA
A
Y50317
36 6.00 KIT, PIPE RACK CONNECTIONEA
A
Y50318
37 2.00 KIT, GORTRAC PAN CONNECTIONEA
A
Y50319
38 1.00 ASSY, GORTRAC PANEA
A
Y50320
39 14.00 KIT, 2IN P-CLAMPEA
A
Y50321
40 34.00 KIT, 3IN P-CLAMPEA
A
Y50322
Printed:
1/31/2014
