ITEM
PART NUMBER
REV
QTY/UNIT
TYPE
DESCRIPTION
MATERIAL
STOCK SIZE
MANUFACTURER
MANUFACTURER PART NO
LENGTH
PROCESS 1 PROCESS 2 PROCESS 3 PROCESS 4
1 161100081
REL-02
1
PURCHASED
MACHINED,SKATE SHEAVE
"SW-Material@161100081.SLDPRT"
"D2@Sketch1@161100081.SLDPRT" "D5@Sketch1@161100081.SLDPRT"
- - - -
2 161100079
REL-04
1
ROUND BAR
AXLE, SKATE SHEAVE
AISI 4140
2"
- -
6 1/2"
- -
MACHINE
ZINC
3 161100080
REL-03
2 TUBE
SPACER, SHEAVE
AISI C1020
2 1/2" X 1/4"
- -
1/2"
- -
MACHINE
ZINC
4 161100290
DEV-03
2
PLATE
MACHINED, ADJUSTMENT BLOCK
G40.21-44W
1 1/2"
- - - - -
MACHINE
ZINC
5
M10499
REL-03
2
PURCHASED
BRG, BALL, 50MM X 110MM X 27MM
- -
FAG
6310-2R3R.C3
- - - - -
REV.
DESCRIPTION
DATE
A
UPDATED DRAWING FORMAT
6/16/2008
REL-06
FIRST MANUAL/ASSEMBLY ISSUE
7/25/2007
REV:
DATE CREATED:
121300003
April 24, 2007 11:54:12 AM
CARRIER SHEAVE ASSY
SHEET 1 OF 1
A
PART NO:
