Canrig PC3000 - AY50144 KIT, ELEC, LOOSE PARTS, PC3000

Engineering
Bill of Material
Part:
KIT, ELEC, LOOSE PARTS, PC3000
Drawing ID:
NO DRAWING
Rev No:
N/A
Item Qty Part ID
Description
Units
Description:
Eng ID:
11
Part:
AY50144
01 2.00 SENSORS, SAFETY BARRIER, 10 - 30 VEA N10302
02 1.00 SENSOR, PROXIMITY, LG, 12-24 V, 3 WIREEA N10300
03 1.00 PROXIMITY CORD, 5M, 250 VEA E12046
04 2.00 STRAIN RELIEF,3/4NPT, 90, (.125 - .250)EA E13744
05 3.00 STRAIN RELIEF, 1/2 NPT, 0.250 - 0.375EA E04-2000-010
06 3.00 STRAIN RELIEF, 3/4 NPT, 0.250 - 0.375EA E04-2007-010
07 2.00 STRAIN RELIEF, 3/4 NPT, 0.625 - 0.750EA E04-2010-010
08 2.00 STRAIN RELIEF, 3/4 NPT, 0.125 - 0.250EA E04-2006-010
09 8.00 FTG, LIQUIDTITE, 3/4 INEA E12398
10 3.00 FTG, LIQUIDTITE, 3/4 IN 90EA E12399
11 4.00 FTG, LIQUIDTITE, 1 INEA E12400
12 105.00 CABLE, 1 C, 16 STRANDS, 18 AWG, REDFT E13660
13 35.00 CABLE, 1 C, 16 STRANDS, 18 AWG, BLKFT E13661
14 150.00 CABLE, 1 C, 16 STRANDS, 18 AWG, GRNFT E13672
15 50.00 CABLE, 1 C, 16 STRANDS, 18 AWG, ORGFT E13675
16 35.00 CABLE, 1 C, 16 STRANDS, 18 AWG, YELFT E13676
17 1.00 FTG, LIQUIDTITE, 1 IN 90EA E12401
18 30.00 CONDUIT, 3/4 SEAL TITEFT E12884
19 20.00 CONDUIT, 1 FLEX, METALLICFT E10563
20 6.00 CONDUIT, LIQUIDTITE, 1-1/4 INFT E12406
21 2.00 TERMINAL, RING, 18-14 AWG, 1/4 IN STUDEA E12390
22 4.00 TERMINAL, STAKONEA E12409
23 3.00 LUG, #2 AWG, 1 HOLE, 5/16 BOLTEA E12943
24 2.00 CONN, CABLE, 1-1/4, JACKETED METAL CLADEA E13459
25 1.00 RECEPTACLE, 100A, 3 WIRE, 4 POLE, RSEA E12538
26 4.00 STRUT, 1-5/8 IN x 2-7/16 INFT M10912
27 4.00 COVER, STRUTFT M10913
28 6.00 SPRINGNUT, 1/4-20UNCEA SN-0250NC
29 50.00 CABLE, V47, POWER VLV AND LEVEL SWFT E12216
30 20.00 CAPSCR, HEX HD, 1/4-20UNC x 1.25, GR8EA HH-0250NC-0125-GR8
31 2.00 CONDUIT, 1/2 RIGIDFT E35-2000-010
32 1.00 CONDUIT, 1/2 RIGID STEEL COUPLINGEA E14111
33 2.00 CONDUIT, STRAP, 1/2, UNISTRUTEA E14112
34 30.00 CABLE, 3 C #18 AWG, 300V, BLACK, WH, REDFT E14300
35 3.00 WIRE, STRANDED, 1C - #6 AWG TEWFT E12384
36 1.00 COVER, DB9 CONNECTOREA E10901
37 200.00 FERRULE, #16 AWG, 14mm, INS, REDEA E16-2018-010
38 1.00 BEACON, WARNING,24VDC,LED,C1D2EA E18079
38A 0.00 KIT, WARNING BEACON, FIELD REPLACEMENTEA
A
Y51069
39 10.00 ASSY, CABLE, 4 PIN, 18 AWG, 5.0 METEREA E14167
Printed:
1/31/2014
