Canrig PC3000 - 121300060 ASSY,COMPACT SKATE,REVERSE VEE

Engineering
Bill of Material
Part:
ASSY,COMPACT SKATE,REVERSE VEE
Drawing ID:
121300060
Rev No:
A
Item Qty Part ID
Description
Units
Description:
Eng ID:
1
Part:
121300060
01 1.00 WELDMENT,SKATE BODY,REVERSE VEEEA 131300006
02 1.00 SKATE CAGEEA 131100155
03 4.00 SKATE RETAINEREA 131100257
04 2.00 SKATE SLIDER PLASTICEA 141500004
05 6.00 CAPSCR, HEX HD, 3/8-16UNC x 2.25, GR8EA HH-0375NC-0225-GR8
06 12.00 WASHER, F, 3/8, PLAIN, TYPE AEA FW-0375-A
07 6.00 LOCKNUT, 3/8-16UNC, NYLOCK, GR8EA LN-0375NC-NL-GR8
08 2.00 CAPSCR, HEX HD, 3/4-10UNC x 3.50, GR8EA HH-0750NC-0350-GR8
09 4.00 WASHER, F, 3/4, PLAIN, TYPE AEA FW-0750-A
10 2.00 LOCKNUT, 3/4-10UNC, NYLOCK, GR8EA LN-0750NC-NL-GR8
11 12.00 CAPSCREW, FLAT HD, 3/8UNC x 1.00EA FH-0375NC-0100
12 1.00 CAPSCR, HEX HD, 1-8UNC x 4.00, GR8EA HH-1000NC-0400-GR8
13 2.00 WASHER, F, 1, PLAIN, TYPE AEA FW-1000-A
14 1.00 LOCKNUT, 1-8UNC, NYLON INSERT, GR8EA LN-1000NC-NL-GR8
15 1.00 GUIDE,SKATE TUBE LEAD INEA 131300007
16 6.00 CAPSCREW, FLAT HD, 1/2UNC x 1.50EA FH-0500NC-0150
17 2.00 WASHER, F, 1/2, PLAIN, TYPE AEA FW-0500-A
18 2.00 CAPSCR, HEX HD, 1/2-13UNC x 1.50, GR8EA HH-0500NC-0150-GR8
19 2.00 LOCKWASHER, 1/2, HELICAL SPRINGEA LW-0500-HS
Printed:
1/31/2014
