Canrig PC3000 - SUBSECTION 7 E: SCHEMATICS

1/31/2014
Serial Number 300390
SUBSECTION 7E: SCHEMATICS
Schematic Description Schematic Rev
EL5002-00 PC3000, PIPE CONTROL SYSTEM INDEX EL5002-00 B
EL5002-04 PC3000, PIPE CONTROL SYSTEM LAYOUT EL5002-04 B
EL5002-05 PC3000, PIPE CONTROL SYSTEM POWER DISTRIBUTION, 120VAC EL5002-05 B
EL5002-06 PC3000, PIPE CONTROL SYSTEM POWER DISTRIBUTION, 24VDC EL5002-06 B
EL5002-07 PC3000, PIPE CONTROL SYSTEM POWER DISTRIBUTION, 24VDC EL5002-07 B
EL5002-08 PC3000, PIPE CONTROL SYSTEM PLC LAYOUT EL5002-08 B
EL5002-09 PC3000, PIPE CONTROL SYSTEM INSTRUMENT LAYOUT EL5002-09 B
EL5002-10 PC3000, PIPE CONTROL SYSTEM PLC LAYOUT EL5002-10 B
EL5002-11 PC3000, PIPE CONTROL SYSTEM PLC LAYOUT EL5002-11 B
EL5002-12 PC3000, PIPE CONTROL SYSTEM PLC LAYOUT EL5002-12 B
EL5002-21 PC3000, PIPE CONTROL SYSTEM PLC SLOT 0, DIGITAL INPUT 1 EL5002-21 B
EL5002-22 PC3000, PIPE CONTROL SYSTEM PLC SLOT 1, DIGITAL INPUT 2 EL5002-22 B
EL5002-23 PC3000, PIPE CONTROL SYSTEM PLC SLOT 2, DIGITAL OUTPUT 1 EL5002-23 B
EL5002-24 PC3000, PIPE CONTROL SYSTEM PLC SLOT 3, DIGITAL OUTPUT 2 EL5002-24 B
EL5002-25 PC3000, PIPE CONTROL SYSTEM PLC SLOT 4, DIGITAL INPUT 3 EL5002-25 B
EL5002-26 PC3000, PIPE CONTROL SYSTEM PLC SLOT 5, ANALOG INPUT EL5002-26 B
EL5002-27 PC3000, PIPE CONTROL SYSTEM PLC SLOT 6, ANALOG OUTPUT EL5002-27 B
EL5002-28 PC3000, PIPE CONTROL SYSTEM PLC SLOT 7 HI, SPEED COUNTER EL5002-28 B
EL5002-29 PC3000, PIPE CONTROL SYSTEM CABLE LAYOUT EL5002-29 B
EL5002-30 EMPTY PAGE EL5002-30 B
EL5002-31 PC3000, PIPE CONTROL SYSTEM SOLA CE1500MH XFMR EL5002-31 B
EL5002-32 PC3000, PIPE CONTROL SYSTEM PLC PANEL ONE-LINE LAYOUT EL5002-32 B
