Canrig PC3000 - Drawing ID: 121300073 Rev No: B

5
763
2334
1
REV. DESCRIPTION DATE
B ADDED HARDWARE AND ITEM 141100595, SEE ECN# CN1357. 11-Dec-2009
A RFM 14-May-2009
ITEM PART NUMBER REV QTY TYPE DESCRIPTION MATERIAL
1 141500021 A 1 PLATE CABLE CAPTURE UHMW
2 HH-0375NC-0150-GR8 A 4 HARDWARE CAPSCR, HEX HD, 3/8-16UNC x 1.50, GR8 -
3 FW-0375-A A 10 HARDWARE WASHER, F, 3/8, PLAIN,TYPE A -
4 LN-0375NC-NL-GR8 A 4 HARDWARE LOCKNUT, 3/8-16UNC, NYLOCK, GR8 -
5 141100595 B 1 PLATE MOUNT, CABLE CAPTURE G40.21-44W / A572 G50
6 LW-0375-HS A 2 HARDWARE LOCKWASHER, 3/8 HELICAL SPRING -
7 HH-0375NC-0100-GR8 A 2 HARDWARE CAPSCR, HEX HD, 3/8-16UNC x 1.00, GR8 -
REV: DATE:
121300073 07-Apr-2009
ASSY, CABLE CAPTURE, CARRIER
1 OF 1 B
DRAWING NO:
