B
A
PLACED INSIDE
ELECTRICAL
PANEL
PLACED ON
J-BOX
PLACED CLOSE
TO APPLETON
CONNECTOR
1
3
3
10
4
19
11
5
6
18
9
8
17
17
2
B B
B
B
5
4
2 4
2
3
11
1
1 2 4 15
4
12
PLACE UNDERNEATH
WINCH
9
DETAIL B
SCALE 1 : 16
7
11
14
DETAIL A
SCALE 1 : 16
16
136
7
B
B
B
B
10/16/2012
OD
ADD DT50286,DT50961,DT50963 & DT50970, QTY OF DT50285 WAS 4.
CN1680
SH
GWL
A
7/22/2009
RFM
REV.
DATE
BY
DESCRIPTION
ECN
CHKD
APVD
ITEM
#
PART #
DESCRIPTION
AY50415
QTY.
AY50416
QTY.
1
DT50233
DANGER KEEP HANDS CLEAR
7 7
2
DT50235
DANGER THIS MACHINE MUST NOT BE OPERATED. . .
4 4
3
DT50238
CAUTION DO NOT ENTER
7 7
4
DT50232
DANGER THIS MACHINE STARTS AUTOMATICALLY
5 5
5
DT50237
CAUTION WATCH YOUR STEP
3 3
6
DT50270
DANGER HIGH VOLTAGE 480 V
2
-
6
DT50271
DANGER HIGH VOLTAGE 600 V
-
2
7
DT50236
DANGER HIGH PRESSURE
2 2
8
DT50266
WARNING TO RESET OVERLOAD . . .
1 1
9
DT50282
5000LBS MAX CAPACITY
6 6
10
DT50288
DANGER PINCH POINT
1 1
11
DT50285
LIGHTNING BOLT GRAPHIC ON YELLOW
3 3
12
DT50239
DANGER KEEP HANDS AND FEET CLEAR
1 1
13
DT50284
DANGER DISCONNECT POWER BEFORE SERVICING
1 1
14
DT50335
WARNING HYDRAULIC FLUIDS ONLY
1 1
15
DT50336
WARNING EP GEAR LUBE ONLY
1 1
16
DT50286
LIGHTNING BOLT GRAPHIC ON YELLOW - LARGE
1 1
17
DT50961
CAUTION MAX RATED CAPACITY 5000LBS
2 2
18
DT50970
LABEL, RAMP LIFT HYDRAULICS
1 1
19
DT50963
NAME PLATE, 'CANRIG', 15X33, SS
1 1
KIT, LABELS, SAFETY, ENG
SEE BOM
07/12/12
JCR
07/12/12
JCR
07/12/12
JCR
SHEET 1 OF 1
1:136
B
185100002
± .010 or as Shown
.005
TRUE POSITION
± 13 mm
7112 & OVER
± 7 mm
3048 TO 7112
± 5 mm
1525 TO 3048
± 2°
FABRICATION
± 1°
MACHINING
± .005"
± 1/2"
280" & OVER
± 1/4"
± 3/16"
120" to 280"
60" to 120"
MIN. RADIUS UNLESS SHOWN = 0.03 MAX.
IF IN DOUBT......PLEASE ASK!
IF IN DOUBT......PLEASE ASK!
WELDING PROCEDURE AS PER CANRIG SPECIFICATION - ENG 704, UNLESS NOTED OTHERWISE
REV
DRAWN
APPRV'D
MATERIAL
CHECKED
.x
.xx
± 1 mm
± 3 mm
DECIMAL
0 TO 610 mm
610 TO 1525
FABRICATING [METRIC]
FABRICATING IMPERIAL
MACHINING IMPERIAL
± .030"
± .015"
EST. WEIGHT
SCALE
± 1/8"
± 1/16"
24" to 60"
0 TO 24"
ANGULAR
.xxx
± 1/16
.005 TIR
CONCENTRICITY
SQUARENESS
STRAIGHTNESS
CASTING
THIS PRINT AND DESIGN AND DETAIL
SHOWN THEREON ARE THE PROPERTY
AND INVENTION OF CANRIG DRILLING
TECHNOLOGY LTD.. THIS PRINT IS
FURNISHED WITH THE UNDERSTANDING
THAT IT IS NOT TO BE REPRODUCED
125
FLATNESS
PARALLELISM
MACHINED SURFACES
UPON DEMAND. ALL RIGHTS OF DESIGN
AND INVENTION ARE RESERVED BY
CANRIG DRILLING TECHNOLOGY LTD..
WITHOUT PERMISSION AND RETURNED
± .010 IN 5 INCHES
REMOVE SHARP CORNERS AND BURRS
- UNLESS OTHERWISE SPECIFIED
TOLERANCE
± .005 IN 5 INCHES
± .010 IN 5 INCHES
x.xx
± .40 mm
± .8 mm
MACHINING METRIC
DECIMAL
x.x
x.
± .13 mm
JCR
MODELED
DO NOT SCALE DRAWING
THIRD ANGLE PROJECTION
07/12/12
57056.1 lbs
A
B
C
D
G
H
I
J
K
A
B
C
D
G
H
J
K
1
2
3
4
5
6
7
1
2
3
4
5
6
7
I
SHEET SIZE
YY/MM/DD
INIT.
D
