Canrig PC3000 - Drawing ID: AY50296 Rev No: B

1
2
3
ITEM PART NUMBER REV QTY/UNIT TYPE DESCRIPTION MATERIAL STOCK SIZE MANUFACTURER MANUFACTURER PART NO LENGTH PROCESS PROCESS 1 PROCESS 2 PROCESS 3 PROCESS 4 WEIGHT
1 FH-0375NC-0150 A 1 HARDWARE CAPSCREW, FLAT HD, 3/8UNC x 1.50 - - - - - 0000 -
2 FW-0375-A A+ 1 HARDWARE WASHER, F, 3/8, PLAIN,TYPE A - - - - - 0000 0.0
3 LN-0375NC-NL-GR8 A 1 HARDWARE LOCKNUT, 3/8-16UNC, NYLOCK, GR8 - - - - - 0000 0.0
REV. DESCRIPTION DATE
REV-02 CHANGE ITEM#1 TO 1-1/2" BOLT SIZE (ECN# CN1523) 09/27/2011
REL-01 RFM 10/26/2007
REV: DATE:
AY50296 9/28/2011
KIT, VERTICAL GUIDE FASTENER
1 OF 1 B
