Canrig PC3000 - 111300015 CARRIER, STYLE RANGE 3, 8 FT SAFETY

Part:
111300015
CARRIER, STYLE RANGE 3, 8 FT SAFETY
Drawing ID:
111300004
Rev No:
D
Item Qty Part ID
Description
Units
Engineering
Bill of Material
Description:
Eng ID:
5
Eng ID
01 1.00 CARRIER MODI,OVERSHOOT DOG POSEA 131101005
02 1.00 ASSY,CABLE GUIDE,CARRIEREA 121300061
0
03 1.00 ASSY,ROLLER,CARRIEREA 121300026
2
04 2.00 ASSY, FRONT ROLLEREA 121300006
2
05 1.00 ASSY, ACCESS COVER, CARRIEREA 121300044
0
06 1.00 ASSY,CBAL VLV,CARRIEREA 121300023
4
07 2.00 SOCKET SET SREW 0.5X0.5EA SS-0500NC-0050-CP
08 2.00 ASSY, LIFT ARM PIVOT, CARRIEREA 121300062
VSA
09 1.00 CARRIER SHEAVE ASSYEA 121300003
1
10 2.00 KIT, SKATE CA ADJUSTMENTEA
A
Y50371
0
11 1.00 KIT, SKATE ADJUSTMENT LOCKEA
A
Y50370
0
12 2.00 ASSY, LIFT ARM JACKING BLOCKEA 121300029
2
13 1.00 ASSY,COMPACT SKATE,REVERSE VEE EA 121300060
1
14 1.00 ASSY,ROPE DEFLECTOR,CARRIEREA 121300005
1
15 6.00 ASSY,KICKER,CARRIEREA 121300031
VSA
16 1.00 ASSY,KICKER CYL ODS MIDDLEEA 121300070
VSA
17 1.00 ASSY, KICKER CYL, DS, MIDDLEEA 121300067
0
18 12.00 GREASE NIPPLE, 1/8 NPT, 90°EA M10668
19 2.00 KIT, 2IN P-CLAMPEA
A
Y50321
0
20 6.00 KIT, CARRIER, 1IN P-CLAMPEA
A
Y50379
0
21 12.00 KIT, CARRIER TRIPLE HOSE CLAMPEA
A
Y50380
1
22 12.00 BULKHEAD, TEE, 8 JIC BRANCHEA H15-070959-08-08
23 6.00 ELL 90°, BULKHEAD, MALE 1/2 JICEA H15-070701-08-08
24 1.00 ASSY,VLV STACK,CARRIEREA 121300024
VSA
25 1.00 ASSY, DIRECTIONAL VLVEA 121300034
0
26 1.00 ASSY, WIRE ROPE, 9/16IN x 113FTEA
A
Y50201
VSA
27 1.00 ASSY, ELEC BOX, CARRIEREA 121300047
0
29 1.00 ASSY, KICKER CYL, DS, FLARE ENDEA 121300068
0
30 1.00 ASSY, KICKER CYL, ODS, FLARE ENDEA 121300071
0
31 1.00 ASSY,REAR ROLLER,CARRIEREA 121300063
0
32 1.00 ASSY,CABLE BLOCK,CARRIEREA 121300065
2
33 1.00 ASSY,OVERSHOOT DOG,CARRIEREA 121300066
0
34 1.00 ASSY, KICKER CYL, ODS, RAMP ENDEA 121300069
0
35 1.00 ASSY, KICKER CYL, DS, RAMP ENDEA 121300032
1
36 6.00 ASSY,SAFETY PIN,CARRIEREA 121300064
VSA
37 1.00 ASSY,SKATE DRIVE,CARRIEREA 121300072
VSA
38 1.00 ASSY,CABLE CAPTURE,CARRIEREA 121300073
1
39 1.00 KIT,CARRIER,1IN P-CLAMP,INNEREA
A
Y50647
0
40 1.00 KIT,CARRIER,2 IN P-CLAMP,INNEREA
A
Y50648
0
Printed:
#Name? Page 1 of
2
