SUBSECTION 7A: CARRIER
Assembly Description
Drawing
Rev
111300015 CARRIER, STYLE RANGE 3, 8 FT SAFETY 111300004 D
121300001 PIPE CARRIER SKATE DRIVE ASSY 121300001 B
121300003 CARRIER SHEAVE ASSY 121300003 A
121300005 ASSY,ROPE DEFLECTOR,CARRIER 121300005 B
121300006 ASSY, FRONT ROLLER 121300006 C
121300019 CARRIER REAR ROLLER 121300019 A
121300023 ASSY,CBAL VLV,CARRIER 121300023 E
121300024 ASSY,VLV STACK,CARRIER 121300024 C
121300026 ASSY,ROLLER,CARRIER 121300026 C
121300027 ASSY, EYEBOLT, CARRIER CABLE 121300027 B
121300028 ASSY, SKATE MOTOR 121300028 B
121300029 ASSY, LIFT ARM JACKING BLOCK 121300029 C
121300031 ASSY,KICKER,CARRIER 121300031 C
121300032 ASSY, KICKER CYL, DS, RAMP END 121300032 C
121300033 ASSY, SAFETY PIN CYL 121300033 B
121300034 ASSY, DIRECTIONAL VLV 121300034 A
121300044 ASSY, ACCESS COVER, CARRIER 121300044 A
121300047 ASSY, ELEC BOX, CARRIER 121300047 A
121300060 ASSY,COMPACT SKATE,REVERSE VEE 121300060 A
121300061 ASSY,CABLE GUIDE,CARRIER 121300061 A
121300062 ASSY, LIFT ARM PIVOT, CARRIER 121300062 A
121300063 ASSY,REAR ROLLER,CARRIER 121300063 A
121300064 ASSY,SAFETY PIN,CARRIER 121300064 B
121300065 ASSY,CABLE BLOCK,CARRIER 121300065 D
121300066 ASSY,OVERSHOOT DOG,CARRIER 121300066 B
121300067 ASSY, KICKER CYL, DS, MIDDLE 121300067 A
121300068 ASSY, KICKER CYL, DS, FLARE END 121300068 A
121300069 ASSY, KICKER CYL, ODS, RAMP END 121300069 A
121300070 ASSY,KICKER CYL ODS MIDDLE 121300070 A
121300071 ASSY, KICKER CYL, ODS, FLARE END 121300071 A
121300072 ASSY,SKATE DRIVE,CARRIER 121300072 B
