1
2
02
02 13/05/22
RSP
REPLACED 131101537 WITH RE-DESIGNED
STAIR CONNECTION PIN (156100402);
REPLACED COTTER PIN M11141 WITH M24-
3002-010; REMOVED WASHER FW-0875-A-N
1957
MZK
JCR
01 12/08/22
TBG
INITIAL DESIGN
JCR
AD
REV
DATE
BY
REVISION DESCRIPTION
ECN
CHKD
APVD
ITEM
QTY
DESCRIPTION
MATERIAL
CANRIG PART No.
1 1
PIN, STAIR CONNECTION
SS TYPE 304
156100402
2 1
COTTER PIN, 3/16 X 2.00
-
M24-3002-010
REV:
DATE:
AY50988
8/22/2012
KIT, STAIR CONNECTION, PC3000
1 OF 1
02
DRAWING NO:
© 2010 CANRIG DRILLING TECHNOLOGY CANADA LIMITED
ALL RIGHTS RESERVED
SHEET:
TITLE:
THE DRAWINGS, INFORMATION AND SUBJECT MATTER HEREOF
ARE THE CONFIDENTIAL, SOLE AND EXCLUSIVE PROPERTY OF
CANRIG DRILLING TECHNOLOGY CANADA LTD, AND ARE NOT
TO BE COPIED, REPRODUCED, OR USED IN ANY MANNER FOR
ANY PURPOSE WHATSOEVER WITHOUT WRITTEN CONSENT
OR DIRECTION.
DRAWN BY:
TBG
