Canrig PC3000 - 121100024 ASSY, HYD, MOTOR & PUMP, 75 HP, 575-600 V

Engineering
Bill of Material
Part:
ASSY, HYD, MOTOR & PUMP, 75HP, 575-600V
Drawing ID:
121100002
Rev No:
C
Item Qty Part ID
Description
Units
Description:
Eng ID:
3
Part:
121100024
01 1.00 ADPT, MALE 3/4 JIC, MALE 3/4 ORBEA H15-070120-12-12
02 1.00 MOTOR, ELEC, 75HP, 575V, 1760 RPMEA E12036
03 1.00 PUMP/MOTOR ADAPTEREA 161900001
04 1.00 FLANGE KIT, SAE, SPLIT, 2 1/2IN, CODE 61EA
A
Y50419
05 1.00 FLANGE KIT, 1-1/4IN, CODE 62EA
A
Y50161
06 1.00 VLV, HYD, CHECK, 1-1/4 IN, SAE 62EA H10490
07 1.00 ELL 90°, CODE 62 FLANGE, MORFS 1 1/4EA H15-LOEQ2-20
08 1.00 ELL 90°, MALE 1/4 JIC, MALE #5 ORBEA H15-070220-04-05
09 1.00 PUMP, PISTON, 145cc, RRW, 5220 PSIEA H10312
10 1.00 ADPT, SUC,3IN B, 2 1/2IN F, 90°EA H10360
11 1.00 CPLG, DRIVE HUB, 1-3/4 BORE, 7/16 KEYEA M12033
12 1.00 CPLG, DRIVE HUB, 2 3/8 IN BOREEA M10518
13 1.00 CPLG, SPIDER ELEMENT, TYPE HEA M10521
14 4.00 CAPSCR, HEX HD, 1/2-13UNC x 1.75, GR8EA HH-0500NC-0175-GR8
15 4.00 CAPSCR, HEX HD, 1/2-13UNC x 4.00, GR8EA HH-0500NC-0400-GR8
16 8.00 CAPSCR, HEX HD, 5/8-11UNC x 2.00, GR8EA HH-0625NC-0200-GR8
17 4.00 CAPSCR, HEX HD, 3/4-10UNC x 2.00, GR8EA HH-0750NC-0200-GR8
18 8.00 LOCKWASHER, 1/2, HELICAL SPRINGEA LW-0500-HS
19 8.00 LOCKWASHER, 5/8 HELICAL SPRINGEA LW-0625-HS
20 4.00 LOCKWASHER, 3/4 HELICAL SPRINGEA LW-0750-HS
21 1.00 CPLG, HYD, TEST POINT, 7/16-20UNFEA H10795
22 0.00 KEY STOCK, 5/8IN x 7/16IN x 2 1/8INEA 156100219
23 0.00 KEY STOCK, 7/16IN x 7/16IN x 2INEA 156100220
Printed:
1/31/2014
