Canrig PC3000 - 121100265 ASSY, HYD RAMP PIVOT SYSTEM, PC3000

Part:
121100265
ASSY, HYD RAMP PIVOT SYSTEM, PC3000
Drawing ID:
121100265
Rev No:
B
Item Qty Part ID
Description
Units
Engineering
Bill of Material
Description:
Eng ID:
9
Eng ID
01 2.00 CYLINDER, HYD, 6.5B, 2.5R, 80.5SEA H11759
02 2.00 CAPSCR, HEX SOC HD, 1/2-13UNC x 3.50EA SH-0500NC-0350
03 8.00 CAPSCR, HEX SOC HD, 1/2-13UNC x 3.25EA SH-0500NC-0325
04 2.00 FTG, GREASE, 1/8 NPT, PTF-SSEA M10533
05 3.00 GREASE NIPPLE, 1/8 NPT, 90°EA M10668
06 1.00 FABRICATION KIT, PC3000, HYD RAMP PIVOTEA
A
Y50926
1
07 2.00 TEE, UNION, 1/2 M JICEA H11057
09 2.00 SNAP RING, INTERNAL, 3-1/8 DIAEA M14136
10 4.00 ADAPTER, FEM SWV 1/2 JIC, 1/2 MALE ORBEA H15-0506-08-08
11 4.00 ASSY, VLV, SINGLE CBAL, #8 ORB,3.0 PILOTEA
A
Y50516
12 4.00 ELL 90°, MALE 1/4 JIC, MALE 1/4 ORBEA H15-070220-04-04
13 4.00 TEE, MALE 1/2 ORB BRANCH, MALE 1/2 JICEA H15-070429-08-08
14 4.00 REDUCER, FEMALE 1/2 JIC, MALE 1/4 JICEA H15-070123-08-04
15 4.00 ELL 90°, MALE 1/2 JIC, MALE 1/2 ORBEA H15-070220-08-08
16 1.00 ASSY, VALVE, SELECTOR, HYD LINES, RAMPEA
A
Y51085
1
R01 1.00 HOSE ASSY, RAMP LIFT CIRCUITEA
A
Y51001
VSA
R02 1.00 HOSE ASSY, HYD RAMP PIVOT, SINGLE CBEA
A
Y51045
0
R03 1.00 STRAIN RELIEF, 1/2 NPT, 0.125 - 0.250EA E04-2001-010
R04 1.00 LOCKNUT, CONDUIT FTG, 1/2 NPTEA E04-5046-010
R05 1.00 SEALING RING, 1/2 NPTEA E04-2027-010
R06 40.00 CABLE,BOSTRIG,600V,3C,18 AWG,SHLDFT 100774
R07 6.00 FERRULE, #18 AWG, 14mm, INS, WHITEEA E11365
R08 1.00 CONNECTOR, SOCKET W/CENTRAL SCREW, 3+PEEA E13664
R09 1.00 GASKET, HIRSCHMANNEA E13699
R10 1.00 CLAMP, SUPPORT, P-TYPE, 2.00 IDEA H10532
R11 1.00 CAPSCR, HEX HD, 3/8-16UNC x 1.25, GR8EA HH-0375NC-0125-GR8
R12 2.00 WASHER, F, 3/8, PLAIN, TYPE AEA FW-0375-A
R13 1.00 LOCKNUT, 3/8-16UNC, NYLOCK, GR8EA LN-0375NC-NL-GR8
R14 1.00 RELAY, 24 VDC, RAIL MOUNT, FORM CEA E10880
R15 1.00 TERMINAL,FUSED,24V INDICATOR,COMBI-FOOTEA E10953
R16 1.00 FUSE, GDC-2A, SLO, 250V, 5 x 20mmEA E33-1007-010
R17 2.00 END BRACKET, TS 35 RAIL, 9.5MMEA E10955
