Canrig PC3000 - Drawing ID: AY50324 Rev No: C

1
3
2
C
C 13/05/27 RSP CHANGED ITEM# 2 PART NO. WAS M10940 1957 MZK JCR
B 11/11/07 -
REPLACED 1/4" COTTER PIN WITH M10940
WITH 1/8" COTTER PIN M11141
- - -
A 09/09/08 - REPLACED FW-1000-A WITH A11171 AS BUILT CN1302 - -
REL-01 07/10/26 - RFM - - -
REV DATE BY REVISION DESCRIPTION ECN CHKD APVD
ITEM QTY DESCRIPTION MATERIAL CANRIG PART No.
1 1 PIN, 1.00 x 5.00 WL, HYDRAULIC RAM BLOCK 450 HTSR 32RC 161100012
2 2 PIN, COTTER, 5/32 X 2.00 - M24-3013-010
3 2 BUSH, MACH, 1 ID x 1 1/2 OD, 14 GAUGE STEEL (3) M11171
REV: DATE:
AY50324 10/19/2007
KIT 2, INDEXER MOUNT
1 OF 1 C
DRAWING NO:
