Canrig PC3000 - 121600001 PIPERACK ARM

Engineering
Bill of Material
Part:
PIPERACK ARM
Drawing ID:
121600001
Rev No:
B
Item Qty Part ID
Description
Units
Description:
Eng ID:
3
Part:
121600001
01 1.00 PIPERACK ARMEA 131100050
02 1.00 JACK PADEA 131100057
03 1.00 CYLINDER MOUNT SPACEREA 152100024
04 1.00 PIN, 1.25 x 7.00 WL PIPE RACKEA 161100016
05 2.00 BUSH, 1 1/4 IN x 1 1/2 IN x 2 INEA M10505
06 1.00 ASSY, VLV, DUAL CBAL, #8 ORB, 3.0 PILOTEA
A
Y50444
07 1.00 FTG, GREASE, 1/8 NPT, PTF-SSEA M10533
08 1.00 CYL, HYD, BORE 4, ROD 3 , STRK 7EA H10367
09 2.00 CAPSCR, HEX HD, 5/16-18UNC x 2.50, GR8EA HH-0312NC-0250-GR8
10 3.00 CAPSCR, HEX HD, 3/8-16UNC x 2.75, GR8EA HH-0375NC-0275-GR8
11 2.00 CAPSCR, HEX HD, 3/8-16UNC x 3.00, GR8EA HH-0375NC-0300-GR8
12 1.00 CAPSCR, HEX HD, 3/4-10UNC X 7.50, GR8EA HH-0750NC-0750-GR8
13 4.00 WASHER, F, 5/16, PLAIN, TYPE A, NARROWEA FW-0312-A-N
14 10.00 WASHER, F, 3/8, PLAIN, TYPE AEA FW-0375-A
15 1.00 WASHER, F, 3/4, PLAIN, TYPE AEA FW-0750-A
17 2.00 LOCKNUT, 5/16-18UNC, NYLOCK, GR8EA LN-0312NC-NL-GR8
18 5.00 LOCKNUT, 3/8-16UNC, NYLOCK, GR8EA LN-0375NC-NL-GR8
19 1.00 LOCKNUT, 3/4-10UNC, NYLOCK, GR8EA LN-0750NC-NL-GR8
20 2.00 ADPT, MALE 1/2 JIC, MALE 1/2 ORBEA H15-070120-08-08
21 4.00 ELL 90°, MALE 1/2 JIC, MALE 1/2 ORBEA H15-070220-08-08
22 3.00 HOSE CLAMP BODY, 20mm, GRP 3 TWINEA M11099
23 3.00 TOP COVER, HOSE CLAMP, TWIN, 3 SEREA H10478
25 1.00 CAPSCR, HEXSOC HD, 3/8-16UNC x 2.00, GR8EA SH-0375NC-0200-GR8
Printed:
1/31/2014
