Canrig PC3000 - Drawing ID: 121300077 Rev No: A

3
2
1
REV. DESCRIPTION DATE
A RFM 6/9/2010
ITEM PART NUMBER REV QTY TYPE DESCRIPTION MATERIAL
1 153100254 A 1 ANGLE BRACKET, HOSE RETAINER, CARRIER G40.21-44W / A572 G50
2 LW-0312-HS A 2 HARDWARE LOCKWASHER, 5/16 HELICAL SPRING -
3 HH-0312NC-0100-GR8 A 2 HARDWARE CAPSCR, HEX HD, 5/16-18UNC X 1.00, GR8 -
REV: DATE:
121300077 6/9/2010
ASSY, HOSE RETAINER BRACKET
1 OF 1 A
DRAWING NO:
© 2009 CANRIG DRILLING TECHNOLOGY CANADA LIMITED
ALL RIGHTS RESERVED
7475 51 Street SE
Calgary, Alberta, Canada, T2C 4L6
Website: www.canrig.com
Bus. (403) 237-6400 Fax. (403) 233-2667
SHEET:
TITLE:
THE DRAWINGS, INFORMATION AND SUBJECT MATTER HEREOF
ARE THE CONFIDENTIAL, SOLE AND EXCLUSIVE PROPERTY OF
CANRIG DRILLING TECHNOLOGY CANADA LTD, AND ARE NOT
TO BE COPIED, REPRODUCED, OR USED IN ANY MANNER FOR
ANY PURPOSE WHATSOEVER WITHOUT WRITTEN CONSENT
OR DIRECTION.
DRAWN BY:
KJH
