5667
12 13 13 14
89910
2
10 9 9 8
16
15
1
3
11
4
18 19 17
15 1/2"
13 3/8"
MAX
REV.
DESCRIPTION
DATE
A
ITEMS 2 AND 15 MODIFIED, SEE ECN# CN1290.
10-Jun-2009
01
ITEM 15 CHANGED.
11-May-2009
00
RFM
3/17/2009
ITEM
PART NUMBER
REV QTY
TYPE
DESCRIPTION
MATERIAL
1 131300006 01 1
WELDMENT
WELDMENT,SKATE BODY, REVERSE VEE
-
2 131100155
C
1
WELDMENT
WELDMENT,SKATE CAGE
-
3 131100257
A
4
WELDMENT
WELDMENT, SKATE RETAINER
-
4 141500004
A
2
PLATE
SKATE SLIDE
UHMW
5
HH-0375NF-0225-GR8
A
6
HARDWARE
CAPSCR, HEX HD, 3/8-24UNF x 2.25, GR8
-
6
FW-0375-A
A
12
HARDWARE
WASHER, F, 3/8, PLAIN,TYPE A
-
7
LN-0375NF-NL-GR8
A
6
HARDWARE
LOCKNUT, 3/8-24UNF, NYLOCK, GR8
-
8
HH-0750NC-0350-GR8
A
2
HARDWARE
CAPSCR, HEX HD, 3/4-10UNC x 3.50, GR8
-
9
FW-0750-A
A
4
HARDWARE
WASHER, F, 3/4, PLAIN, TYPE A
-
10
LN-0750NC-NL-GR8
A
2
HARDWARE
LOCKNUT, 3/4-10UNC, NYLOCK, GR8
-
11
FH-0375NC-0075
A
12
HARDWARE
CAPSCREW, FLAT HD, 3/8UNC x 0.75
-
12
HH-1000NC-0400-GR8
A
1
HARDWARE
CAPSCR, HEX HD, 1-8UNC x 4.00, GR8
-
13
FW-1000-A
A
2
HARDWARE
WASHER, F, 1, PLAIN, TYPE A
-
14
LN-1000NC-NL-GR8
A
1
HARDWARE
LOCKNUT, 1-8UNC, NYLOCK, GR8
-
15 131300007
A
1
ASSEMBLY
GUIDE, SKATE TUBE LEAD IN
-
16
FH-0500NC-0150
A
6
HARDWARE
CAPSCREW, FLAT HD, 1/2UNC x 1.50
-
17
FW-0500-A
A
2
HARDWARE
WASHER, F, 1/2, PLAIN, TYPE A
-
18
HH-0500NC-0150-GR8
A
2
HARDWARE
CAPSCR, HEX HD, 1/2-13UNC x 1.50, GR8
-
19
LW-0500-HS
A
2
HARDWARE
LOCKWASHER, 1/2 HELICAL SPRING
-
REV:
DATE:
121300060
16-Mar-2009
ASSY, COMPACT SKATE, REVERSE VEE
1 OF 1
A
DRAWING NO:
© 2009 CANRIG DRILLING TECHNOLOGY CANADA LIMITED
ALL RIGHTS RESERVED
7475 51 Street SE
Calgary, Alberta, Canada, T2C 4L6
Website: www.canrig.com
Bus. (403) 237-6400 Fax. (403) 233-2667
SHEET:
TITLE:
THE DRAWINGS, INFORMATION AND SUBJECT MATTER HEREOF
ARE THE CONFIDENTIAL, SOLE AND EXCLUSIVE PROPERTY OF
CANRIG DRILLING TECHNOLOGY CANADA LTD, AND ARE NOT
TO BE COPIED, REPRODUCED, OR USED IN ANY MANNER FOR
ANY PURPOSE WHATSOEVER WITHOUT WRITTEN CONSENT
OR DIRECTION.
DRAWN BY:
BK
