1
4
3
2
6
5
B
6X WASHER FOR
LOCKNUT (ITEM #3)
HIDDEN IN VIEW
B
13/03/26
RSP
REPLACED WEDGE & ADDED THREADED
CONNECTOR
2047
MZK
JCR
A
10/05/24
UPDATED HARDWARE
CN1403
REL-
01
07/10/26
KJH
RFM
REV
DATE
BY
REVISION DESCRIPTION
ECN
CHKD
APVD
ITEM
QTY
DESCRIPTION
MATERIAL
CANRIG PART No.
1 13
WELDMENT, PIPERACK ARM RETAINING PLATE
SEE BOM
131100087
2 6
LOCKNUT, 5/8-11UNC, NYLOCK, GR8
GR8
LN-0625NC-NL-GR8
3 12
WASHER, F, 5/8, PLAIN, TYPE A
GR8
FW-0625-A
4 6
CAPSCR, HEX HD, 5/8-11UNC x 2.50, GR8
GR8
HH-0625NC-0250-GR8
5 1
QUICK LINK, THREADED CONNECTOR, 3/8
Alloy Steel
M11128
6 1
PLATE, RACK POSI-WEDGE
G40.21-44W / A572 G50
141100292
REV:
DATE:
AY50318
10/18/2007
ASSEMBLY, PIPE RACK CONNECTION
1 OF 1
B
DRAWING NO:
© 2009 CANRIG DRILLING TECHNOLOGY CANADA LIMITED
ALL RIGHTS RESERVED
7475 51 Street SE
Calgary, Alberta, Canada, T2C 4L6
Website: www.canrig.com
Bus. (403) 237-6400 Fax. (403) 233-2667
SHEET:
TITLE:
THE DRAWINGS, INFORMATION AND SUBJECT MATTER HEREOF
ARE THE CONFIDENTIAL, SOLE AND EXCLUSIVE PROPERTY OF
CANRIG DRILLING TECHNOLOGY CANADA LTD, AND ARE NOT
TO BE COPIED, REPRODUCED, OR USED IN ANY MANNER FOR
ANY PURPOSE WHATSOEVER WITHOUT WRITTEN CONSENT
OR DIRECTION.
DRAWN BY:
KJH
