111300004.SLDDRW ()
7 of 7
D
7 OF 7
CARRIER, STYLE RANGE 3
5/26/2009
111300004
REV:
7475 51 Street SE
Calgary, Alberta, Canada, T2C 4L6
Website: www.canrig.com
Bus. (403) 237-6400 Fax. (403) 233-2667
THE DRAWINGS, INFORMATION AND SUBJECT MATTER HEREOF
ARE THE CONFIDENTIAL, SOLE AND EXCLUSIVE PROPERTY OF
CANRIG DRILLING TECHNOLOGY CANADA LTD, AND ARE NOT
TO BE COPIED, REPRODUCED, OR USED IN ANY MANNER FOR
ANY PURPOSE WHATSOEVER WITHOUT WRITTEN CONSENT
OR DIRECTION.
© 2009 CANRIG DRILLING TECHNOLOGY CANADA LIMITED
ALL RIGHTS RESERVED
SHEET:DRAWN BY: DATE:
TITLE:
DRAWING NO:
KJH
AL AL
AN
AN
AM
SECTION AL-AL
1 5/8"
1 3/4"
4 7/8"
3 3/8"
1"
DETAIL AM
TAP 5/16" THRU
3/8-16UNC THRU HSS
BEFORE INSTALLING BRACKET
41
1
AO
SECTION AN-AN
DETAIL AO
41
1
FLUSH
