Canrig PC3000 - 121100123 ASSY,HYD TANK,PC3000,600 V

Engineering
Bill of Material
Part:
ASSY,HYD TANK,PC3000,600V
Drawing ID:
121100004
Rev No: F
Item Qty Part ID
Description
Units
Description:
Eng ID:
3
Part:
121100123
01 1.00 ASSY,FILTER,HYD TANKEA 121900065
02 1.00 HYDRAULIC RESERVOIREA 131100020
03 1.00 RESERVOIR LIDEA 131100174
04 1.00 CONTROL GUARDEA 131100510
05 1.00 PANEL GUARDEA 131100511
06 1.00 GASKET, HYDRAULIC RESERVOIREA 141500011
07 1.00 PIN, .50 x 15.81 WL, CONTROL GUARD HINGEEA 161100275
08 1.00 ASSY, CONTROL CONSOLE, PC3000EA AY50142
09 1.
00 HEATER, ELEC, IMMERSION, 575-600V, 1.5KWEA E12063
10 2.00 ADPT, MALE 3/4 JIC, MALE 3/4 NPTEA H15-070102-12-12
11 2.00 ELL 90°, MALE 1/2 JIC, MALE 1/2 NPTEA H15-070202-08-08
12 1.00 ELL 90°, MALE 3/4 NPT, FEM 3/4 JICEA H15-2250-12-12
13 1.00 FILTER, ELEMENT, 10 MICRON, SPIN ONEA H10342
14 1.00 ELEMENT, FILTER, CASE DRAIN, 10 MICRONEA H10347
15 1.00 FILTER, CASE DRAIN, 3/4 NPT, INLINEEA H10348
16 1.00 NIPPLE, KING, PIPE 3IN, HOSE 3INEA H10362
17 1.00 NIPPLE, PUMP, 3IN, CLOSE, SUCTIONEA H10363
18 1.00 PLUG, RESERVOIR, 2.0 NPTEA H10406
19 1.00 PLUG, RESERVOIR, 1.25 NPTEA H10407
20 2.00 PLUG, PIPE, 0.75IN NPTEA H10495
21 1.00 NIPPLE, PUMP, 3/4 IN, CLOSE, SUCTIONEA H10569
22 1.00 VLV, BALL, 3 IN NPT, 600 PSI WOGEA H10442
23 1.00 VLV, BALL, 3/4 IN NPT, 600 PSI WOGEA H10443
27 1.00 TRANSMITTER, TEMP, -60 TO 200C,3/4 NPTEA N10660
27A 0.00 THERMOWELL, TEMP, 2.5 INSERTION, 4 STEMEA N10299
28 6.00 CAPSCR, HEX HD, 3/8-16UNC x 1.00, GR8EA HH-0375NC-0100-GR8
29 4.00 CAPSCR, HEX HD, 3/8-16UNC x 1.25, GR8EA HH-0375NC-0125-GR8
30 18.00 WASHER, F, 3/8, PLAIN, TYPE AEA FW-0375-A
31 2.00 WASHER, F, 1/2, PLAIN, TYPE AEA FW-0500-A
32 10.00 LOCKWASHER, 3/8 HELICAL SPRINGEA LW-0375-HS
33 2.00 COTTER PIN, 3/16 X 1.50EA M10207
34 6.00 SPRINGNUT, 3/8-16UNCEA SN-0375NC
35 16.00 CAPSCR, HEX SOC HD, 3/8-16UNC x 1.25EA SH-0375NC-0125
36 16.00 LOCKNUT, 3/8-16UNC, NYLOCK, GR8EA LN-0375NC-NL-GR8
37 1.00 ADAPTER,STR,1 MALE JIC,3/4 MALE NPTEA H15-070102-16-12
38 1.00 ELL 90°, MALE 3/4 JIC, MALE 3/4 NPTEA H15-070202-12-12
39 1.00 TEE, FEM, SWV BRANCH, MALE 1-1/4 JICEA H15-070433-20
40 1.00 CAP NUT, 1-1/4EA H10530
41 2.00 WASHER, BRITISH BONDED SEAL, SIZE 4EA S10116
42 2.00 LOCKNUT, 1/2-13UNC, NYLOCK, GR8EA LN-0500NC-NL-GR8
Printed:
1/31/2014
