Canrig PC3000 - 121300072 ASSY,SKATE DRIVE,CARRIER

Engineering
Bill of Material
Part:
ASSY,SKATE DRIVE,CARRIER
Drawing ID:
121300072
Rev No:
B
Item Qty Part ID
Description
Units
Description:
Eng ID:
1
Part:
121300072
01 1.00 PIPE CARRIER SKATE DRIVE ASSYEA 121300001
02 1.00 SKATE DRIVE MOTOR MOUNTEA 131100151
03 1.00 ASSY, SKATE MOTOREA 121300028
04 1.00 SPROCKET, DOUBLE #60 15 TEETHEA 161100202
05 1.00 CHAIN, SKATE DRIVE, 60 H, 46 1/2 LGEA M10696
06 1.00 CHAIN CONNECTOR, DAIDO, #60-2EA M11208
07 1.00 TRNBKL, JAW & JAW, 1x18, J&J GALVANIZEDEA M10974
08 12.00 CAPSCR, HEX HD, 1/2-13UNC x 1.50, GR8EA HH-0500NC-0150-GR8
09 12.00 LOCKWASHER, 1/2, HELICAL SPRINGEA LW-0500-HS
10 12.00 WASHER, F, 7/16, PLAIN, TYPE A, NARROWEA FW-0437-A-N
11 4.00 CAPSCR, HEX HD, 1/2-13UNC x 2.75, GR8EA HH-0500NC-0275-GR8
12 8.00 WASHER, F, 1/2, PLAIN, TYPE AEA FW-0500-A
13 4.00 LOCKNUT, 1/2-13UNC, NYLOCK, GR8EA LN-0500NC-NL-GR8
14 1.00 RETNG RING, EXT, 1.50 SHAFT, 0.050 THKEA M10574
Printed:
1/31/2014
