Canrig PC3000 - Drawing ID: AY50652 Rev No: A

OFF DRILLER SIDE
1
2
DRILLER SIDE
1
2
NOTE:
WILL BE RE-USED WHEN INSTALLING ITEMS 1 AND 2.
REV.
DESCRIPTION
DATE
A
RFM
14-May-2009
ITEM
PART NUMBER
REV
DS PIN DOWN
POSITION/QTY.
TYPE
DESCRIPTION
MATERIAL
1 141102537 02 2
PLATE
ARM, LONG, SAFETY PIN
G40.21-44W /
A572 G50
2 156100259 01 1
ROUND BAR
PIN, SAFETY, LONG
AISI 4140
A
1 OF 1
PC3000 LONG SAFETY PIN RETRO-FIT
30-Mar-2009
AY50652
REV:
7475 51 Street SE
Calgary, Alberta, Canada, T2C 4L6
Website: www.canrig.com
Bus. (403) 237-6400 Fax. (403) 233-2667
