Canrig PC3000 - 121100301 ASSY, 11 F-8 IN LIFT ARM

Engineering
Bill of Material
Part:
ASSY, 11F-8IN LIFT ARM
Drawing ID:
121100301
Rev No:
01
Item Qty Part ID
Description
Units
Description:
Eng ID:
0
Part:
121100301
01 1.00 WELDMENT, 11F-8IN, LIFT ARM FRAMEEA 131101572
02 2.00 3/8IN LIFT ARM SPACEREA 141100447
03 6.00 1/8IN LIFT ARM SPACEREA 141100448
04 1.00 GORTRAC, UHMW SLIDEEA 141500076
05 2.00 LIFTING ARM BEARING PADEA 141500077
06 1.00 LIFT ARM HINGE PINEA 161100009
07 2.00 LIFT ARM POCKET ROLLEREA 161100053
08 2.00 RETAINING RING, SPIRAL, EXT, 2.50 INEA M10492
09 4.00 ADAPTER 1 INCH M JIC X 1 INCH NPT FEMALEEA H15-070103-16-16
10 2.00 CLAMP, BODY HALVES, PLASTICEA H10801
11 1.00 PLATE, COVER, 1/2IN, HEAVYEA H10803
12 2.00 FTG, GREASE, 1/8 NPT, PTF-SSEA M10533
13 2.00 THRDED ROD, 3/8-16UNC, 6.5IN, GR8EA TR-0375NC-GR8-0.55
14 1.00 CAPSCR, HEX HD, 5/16-18UNC x 4.50, GR8EA HH-0312NC-0450-GR8
15 2.00 CAPSCREW, FLAT HD, 3/8UNC x 1.75EA FH-0375NC-0175
16 20.00 CAPSCREW, FLAT HD, 1/4-20UNC x 1.00EA FH-0250NC-0100
17 2.00 LOCKWASHER, 3/8 HELICAL SPRINGEA LW-0375-HS
18 2.00 WASHER, F, 5/16, PLAIN, TYPE AEA FW-0312-A
19 2.00 LOCKNUT, 3/8-16UNC, NYLOCK, GR8EA LN-0375NC-NL-GR8
20 1.00 LOCKNUT, 5/16-18UNC, NYLOCK, GR8EA LN-0312NC-NL-GR8
Printed:
1/31/2014
