Specifications
Canrig Drilling Technology Ltd. 2-1
Canrig PC3000-26 Specifications
This chapter contains product specifications and includes Certificate of Performance.
Table 2-1 lists available specifications for the Canrig PC3000 with 26" Deck Automated Power Catwalk.
Table 2-1: Specifications for the Canrig PC3000-26
Description Imperial Metric
Tubular length, max. 45 ft, range 3, single 13.7 m, range 3, single
Tubular OD, max. 20 in 50.8 cm
Carrier lift capacity, max. 10,000 lbs 4,536 kg
Ramp weight 12,000 – 18,000 lbs 5,443 – 8,165 kg
Cycle time, approx.
(Catwalk base to rig floor; travel
time based on ramp length)
20 – 54 sec 20 – 54 sec
Drill floor height 18 – 35 ft 5.5 – 10.7 m
Catwalk height 26 in 66 cm
Dimensions, working
H x 9.5 ft W x 60 ft L
H = Height of rig floor
H x 2.9 m W x 18.3 m L
H = Height of rig floor
Dimensions, transport 10.5 ft H x 9.5 ft W x 60 ft L 3.2 m H x 2.9 m W x 18.3 m L
Weight, unloaded, approx. 57,000 lbs 25,855 kg
HPU drive system Electric Electric
HPU power 75 HP 55.2 kW
Power supply
575 – 600V / 3Ø / 60 Hz
460 – 480V / 3Ø / 60 Hz
380V / 3Ø / 50 Hz
575 – 600V / 3Ø / 60 Hz
460 – 480V / 3Ø / 60 Hz
380V / 3Ø / 50 Hz
Pipe rack capacity, max. 20,000 lbs per pipe rack 9,072 kg
Carrier cable capacity, max. 2,000 ton miles 28,600 mega joules
