PC3000 with 26" Deck (PC3000-26) User’s Manual
3-8 Document ID 13-003 v 2.0
Figure 3-7: Skate
Caution
• DO NOT use the kickers if the skate is in the way.
• DO NOT run the skate into the stop plates located
under the top carrier plate near each end of the
carrier. This will cause damage to the skate
assembly and shorten the life of the skate cables.
Skate
See Figure 3-2
for reference.
