PC3000 with 26" Deck (PC3000-26) User’s Manual
3-16 Document ID 13-003 v 2.0
Figure 3-15: Hydraulic Tank
Figure 3-16: Return Oil Filter Pressure Gauge
In-tank
Return Filter
Oil
Temperature
Gauge
Low Oil
Level Switch
Add Oil
Level
Pump Case
Drain Filter
Tank
Breather Filter
Full Oil
Level
Amber Strobe Light
In-tank
Return Filter
Pressure Gauge
