Canrig PC3000 - Page 373

Engineering
Bill of Material
41 4.00 SHEAVE SEAL, 0.437 x 0.062 x 3.375EA S10081
42 0.00 CAPSCR, HEX SOC HD, 3/8-16UNC x 1.00EA SH-0375NC-0100
43 8.00 WASHER, F, 3/4, PLAIN, TYPE AEA FW-0750-A
44 13.00 WASHER, F, 3/8, PLAIN, TYPE AEA FW-0375-A
45 8.00 WASHER, F, 1.25, PLAIN, TYPE A, 2.50 ODEA FW-1250-A
46 12.00 LOCKWASHER, 3/4 HELICAL SPRINGEA LW-0750-HS
47 4.00 LOCKWASHER, 3/8 HELICAL SPR, HIGH COLLAREA LW-0375-HS-HC
48 10.00 LOCKWASHER, 3/8 HELICAL SPRINGEA LW-0375-HS
49 4.00 LOCKNUT, 1 1/4-7UNC, GR8, NYLOCKEA LN-1250NC-NL-GR8
50 2.00 LOCKNUT, 3/4-10UNC, NYLOCK, GR8EA LN-0750NC-NL-GR8
51 2.00 LOCKNUT, 3/8-16UNC, NYLOCK, GR8EA LN-0375NC-NL-GR8
52 1.00 ELL 90°, FEM 1/2 JIC, MALE 1/2 JICEA H15-070221-08-08
R01 1.00 HOSE ASSY, RAMP, 6000PSI, PC3000EA
A
Y51039
R02 2.00 OIL, MOBIL GEAREA C10139
R03 1.00 RAMP, HANGER INSTALLATION, PC3000EA DT50791
R04 2.00 PIN, COTTER, 1/4 X 2.50EA M10940
R05 1.00 LABEL, RAMP LIFT HYDRAULICSEA DT50970
Printed:
1/31/2014
