PC3000 with 26" Deck (PC3000-26) User’s Manual
6-4 Document ID 13-003 v 2.0
2. Grease each grease zerk on the kicker cylinders and pivot assembly (Figure 6-4). Also grease the
safety pin cylinders (Figure 6-5).
Figure 6-4: Kicker Grease Points
Figure 6-5: Pivot Assembly and Safety Pin Grease Points
Grease Points
(Both Sides)
Grease Points
