4. Program Sequence
62000H Series DC Power Supplies with Solar Array Simulation allow users to program the
output sequence in LIST MODE, V_STEP MODE and IV PROGRAM. LIST MODE and IV
PROGRAM both have 10 Programs and each Program can add a total of 100 sequences that
are available for editing. IV PROGRAM is used to edit the IV Curve waveform. V_STEP
MODE provides a run time voltage program with a maximum of 99 hours 59 minutes and 59
seconds.
Each sequence in LIST MODE can be edited for voltage settings, voltage slew rates, current
settings, current slew rates, run times and trigger types that can apply to almost any situation.
1. Press “
” on the front panel.
2. The PROGRAM options are displayed as shown in Figure 4-1.
3. Use the numeric keys
- or the “Rotary” ( ) knob to set the desired
mode.
4. Press “ ” to confirm.
5. To quit the PROGRAM mode, press “ ” to return to the MAIN PAGE.
Figure 4-1
4.1 LIST MODE
In LIST MODE a maximum of 100 sequences may be added per program. The setting
sequence is described in section 4.1.2 and the complete program structure is listed in Figure
4-2.
P R O G R A M M O D E = L I S T _
[ P R O G R A M ]
1.
L I S T M O D E
2. V
_ S T E P M O D E
3.
I V P R O G R A M
To Next Page
