4.1.2.3 Setting Time
1. Use the “ ”, “ ” keys to move the cursor to the column to be set as shown in
Figure 4-8 (3).
2. Use the numeric keys
0
-
9
or the “Rotary” ( ) knob to set the value.
3. This function sets the time duration of a sequence. The TIME = setting only appears
when SEQ. TYPE = AUTO.
4. Press “ ” to confirm.
5. Press “ ” to return to the Program PAGE (Figure 4-3).
4.1.2.4 Setting Voltage
1. Use the “ ”, “ ” keys to move the cursor to the column to be set as shown in
Figure 4-8 (4).
2. Use the numeric keys
0
-
9
or the “Rotary” ( ) knob to set the SEQ output
voltage
3. Press “ ” to confirm.
4. Press “ ” to return to the Program PAGE (Figure 4-3).
See section 3.2 for a detailed description.
4.1.2.5 Setting Voltage Slew Rate
1. Use the “ ”, “ ” keys to move the cursor to the column to be set as shown in
Figure 4-8 (5).
2. Use the numeric keys
0
-
9
or the “Rotary” ( ) knob to set the SEQ
voltage conversion slew rate.
3. Press “ ” to confirm.
4. Press “ ” to return to Program PAGE (Figure 4-3).
See section 3.3.2.3 for a detailed description.
4.1.2.6 Setting Current
1. Use the “ ”, “ ” keys to move the cursor to the column to be set as shown in
Figure 4-8 (6).
2. Use the numeric keys
0
-
9
or the “Rotary” ( ) knob to set the SEQ output
current limit.
3. Press “ ” to confirm.
4. Press “ ” to return to Program PAGE (Figure 4-3).
See section 3.2 for a detailed description.
ENTER
EXIT
ENTER
EXIT
ENTER
EXIT
ENTER
EXIT
