Programmable DC Power Supply (with Solar Array Simulation) 62000H Series
Operating & Programming Manual
4.3.3.2 IV Program Main Screen
When the IV PROGRAM is running, the main screen will display the following information.
Items (1) - (10) in Figure 4-32 are described below.
Figure 4-32
(1) IV-Sequence status: SEQ STATUS shows the IV-Sequence status currently running.
(2) Total Time accumulated: TIME shows the total time accumulated from the execution of
the IV-PROGRAM to the IV-Sequence on the IV-Main Page. The time format is
HOUR:MIN:SEC. The maximum time displayed is 99 hours 59 minutes and 59 seconds.
If the accumulated time exceeds the maximum time display, it will reset to zero and
re-accumulate.
(3) IV-Program Number: PROG. shows the IV-Program Number being executed.
(4) IV-Sequence Number: SEQ. shows the IV-Sequence Number being executed.
(5) IV-FILE Number: FILE. shows the IV-FILE Number being executed.
(6) Count_Remain : CNT_REMAIN shows the number of IV-Programs to be executed.
(7) Open Circuit Voltage: VOC shows the open circuit voltage of the IV-FILE Number being
executed.
(8) Short Circuit Current: ISC shows the short circuit current of the IV-FILE Number being
executed.
(9) Max. Power Voltage: VMP shows the maximum power voltage of the IV-FILE Number
being executed.
(10) Max. Power Current: IMP shows the maximum power current of the IV-FILE Number
being executed.
S E Q S T A T U S =
A U T O T I M E = 0 0 0 : 0 0 : 20
P R O G . = 1 S E Q . = 1 F I L E . =0 C N T _
R E M A I N
= 0
1 0 0 . 0 0
V 0 . 0 0 0 0 A
V O C = 1 0 0 . 0 0 V I S C = 1 0
.
0 0 0 A
0 . 0 W
V M P = 9 0 . 0 0 V I M P = 9 . 0 0 0 A
( 1 ) (
2
)
( 3 )
( 4 ) ( 5 ) (
6
)
( 7 )
(
8
)
( 9
)
( 10 )
