Chroma A620028 - Execution of V_STEP MODE; Running V_STEP MODE

Program Sequence
4-19
Figure 4-21
Figure 4-22
4.2.2 Execution of V_STEP MODE
Once all the sequences have been programmed, press “
ON/OFF
” to start execution. Press
“ ” to stop execution.
4.2.2.1 Running V_STEP MODE
1. Pressing “
ON/OFF
” will display a confirmation window as shown in Figure 4-15.
2. Press “
ON/OFF
” one more time to confirm the execution. The display will go to the MAIN
PAGE during execution as shown in Figure 4-23. To stop the execution, press “ ”
to return to the MAIN PAGE screen.
Pressing “
EXIT
” will abort the executing program and shut off the Power
Supply output.
START
10(MIN)
50V
10
V
START
10(MIN)
50V
20V
10V
EXIT
EXIT
