Programmable DC Power Supply (with Solar Array Simulation) 62000H Series
Operating & Programming Manual
[ C A L I B R A T I O N ]
P A S S W O R D:
Figure 3-100
2. Enter the password and press “ ” to confirm. The screen will display 4 calibration
options as shown in Figure 3-101. The calibration steps are described in sections 3.3.7.1
to 3.3.7.5.
3. To abort the CALIBRATION, press “
” to return to the MAIN PAGE.
C H O I C E = V O L T A G E [ P / M ] [ C A L I B R A T I O N ]
1. V O L T A G E [ P R O G . / M E A S . ]
2. C U R R E N T
[ M E A S . ]
3. C U R R E N T
[ P R O G .
]
4. A P G V O L T A G E [ P R O G . / M E A S . ]
5. A P G C U R R E N T
[ P R O G . / M E A S . ]
Figure 3-101
The slave models (A620028/A620027) of the Chroma 62000H Series DC Power Supplies
with Solar Array Simulation have 3 CALIBRATION functions:
(1) VOLTAGE: the actual output voltage (CV mode) and the measurement accuracy.
(2) CURRENT: the measurement accuracy of the current.
(3) CURRENT: the actual output current (CC mode).
1. The A620028/A620027 SLAVE models must be calibrated through the MASTER unit.
First execute the steps described in sections 3.3.3.3.2 to 3.3.3.3.5 and return to the main
screen when the parallel setting is done. Press Config, “ ” then “ ” to enter
into the SERIES/PARALLEL selection. Use the “
”, “ ” keys to move the
cursor to PAGE2 and select IDN using the “Rotary Knob” (
) as shown in Figure 3-102.
Confirm the ID address of the SLAVE to be calibrated. The yellow light on the panel of
the selected SLAVE will blink.
