Programmable DC Power Supply (with Solar Array Simulation) 62000H Series
Operating & Programming Manual
3-42
This function sets the protection point for Over Current. If the output current exceeds the
range, it will turn off the output to protect the unit under test.
Table 3-3 shows the current range of OCP.
Table 3-3
Model
Min. OCP (A)
Max. OCP (A)
62xxxH-xxxxS
0
1.05 x Io_MAX
If an OCP occurs the MAIN PAGE will display a protection message as shown in Figure 3-72.
V = 6 0. 0 0 V I = 1 0. 0 0 _ A O F F
0 . 0 0 0 0 V 0 . 0 0 0 0 A
O C P 0 . 0 W
Figure 3-72
3.3.5.3 OPP Protection
1. Use the “ ”, “ ” keys to move the cursor to the column to be set as shown in
Figure 3-73.
[ P R O T E C T I O N ]
O V P
= 6 0 0 . 0 _
V
O C P = 1 8 . 9 0 A
O P P =
5 2 5 0 . 0 W
R E M O T E I N H I B I T = D I S A B L E P U L L = H I G H
S A F E T Y I N T . L O C K =
D I S A B L E P U L L
=
H I G H
E X T O N / O F F = D I S A B L E P U L L = H I G H
▼
Figure 3-73
2. Use the numeric keys (
0
-
9
) or the “Rotary” ( ) knob to set the value.
3. Press “ ” to confirm.
4. Press “
EXIT
” to return to the MAIN PAGE.
This function sets the protection point for Over Power. If the output power exceeds the range,
it will turn off the output to protect the unit under test.
ENTER
