Programmable DC Power Supply (with Solar Array Simulation) 62000H Series
Operating & Programming Manual
17. Current programming: inputs the analog voltage (0-10Vdc or 0-5Vdc) between this pin
and APIGND to linearly control the output current (CC mode).
18. Current measurement: outputs the analog current (4mA-20mA) for monitoring.
19. Current measurement: outputs the analog voltage (0-5V or 0-10V) for monitoring.
3.3.1.2 BUZZER
The buzzer sounds when the keys or the rotary knob on the front panel are pressed or turned.
It can be turned off if an audio response is not necessary. (The default is ON.)
1.
Use the “ ”, “ ” keys to move the cursor to the column to be set as shown in
Figure 3-11.
[
S Y S T E M S E T U P
]
A P G V S E T
=
N O N E _
A P G I S E T
=
N O N E
A P G V M E A S =
N O N E
A P G I M E A S
=
N O N E
B U Z Z E R
=
O N
P O W E R O N S T A T U S
=
D E F A U L T
Figure 3-11
2.
Use the numeric keys ( -
) or the “Rotary”( ) knob to select “ON” or “OFF”
mode.
3. Press “ ” to confirm.
4.
Press “ ” to return to the MAIN PAGE.
1. The BUZZER has two options: ON / OFF. (Default is ON).
2. When the BUZZER is set to ON, pressing any key or turning the
rotary knob will sound the buzzer.
3. When the BUZZER is set to ON, the BUZZER will beep continuously
if a system protection error occurs.
4. When the BUZZER is set to OFF it will not beep in any situation.
3.3.1.3 POWER ON STATUS
Automatically loads the default output status when the unit is powered ON.
1.
Use the “ ”, “ ” keys to move the cursor to the column to be set as shown in
Figure 3-12.
