Chroma A620028 - Setting PROG CHAIN

Program Sequence
4-5
4.1.1.4 Setting PROG CHAIN
1. Use the “ ”, “ ” keys to move the cursor to the column to be set as shown in
Figure 4-3 (4).
2. Use the numeric keys
0
- or the “Rotary” ( ) knob to set YES or NO.
The PROGRAM CHAIN indicates the link between programs. YES must be set before
executing different programs, and then select the PROGRAM to be executed next (NEXT
TO PROG NO.).
The setting range is 0 - 10.
(1) Set NEXT TO PROG NO. to 0
Setting NEXT TO PROG NO. to 0 disables program linking.
(2) Set NEXT TO PROG NO. to non 0
Setting NEXT TO PROG NO. to non-0 enables program linking, as shown below.
Ex.: Link execution among programs
Set PROG #1 to NEXT TO PROG NO =3, RUN COUNT=1
PROG #3 to NEXT TO PROG NO =4, RUN COUNT=1
PROG #4 to NEXT TO PROG NO =6, RUN COUNT=1
PROG #6 to NEXT TO PROG NO =0, RUN COUNT=1
The program execution flow is listed as Figure 4-5 shows.
A2: Execution steps:
(1) When all PROG #1 SEQUENCES are done, skip PROG #2 and jump to PROG
#3
(2) When all PROG #3 SEQUENCES are done, jump to PROG #4
(3) When all PROG #4 SEQUENCES are done, skip PROG #5 and jump to PROG
#6
(4) End
