Manual Operation
3-29
Using the 62150H-600S as an example:
1. If there are 5 sets connected in parallel for 600V/100A, each unit
should be set for 600V/20A and the total output will be 600V/100A.
2. If there are 2 sets connected in series for 1200V/25A, each unit
should be set for 600V/25A and the total output will be 1200V/25A.
3. A maximum of 2 units may be connected in series; therefore, the
maximum number of NUM. OF SLAVE is 1.
4. A maximum of 10 units may be connected in parallel; therefore, the
maximum number of NUM. OF SLAVE is 9.
3.3.3.3.5 Activating MASTER & SLAVE CONTROL
When connecting units in PARALLEL OR SERIES, set NUM. OF SLAVE in the MASTER unit
as described below:
1. Use the “
”, “ ” keys to move the cursor to the column to be set as shown in
Figure 3-44.
2. Use the numeric key ( ) or the “Rotary” (
) knob to set YES.
[ S E R I E S / P A R A L L E L ]
M A S T E R O R S L A V E
= M A S T E R
M / S T E R M I N A T O R = D I S A B L E
P A R A L L E L O R S E R I E S = P A R A L L E L
N U M . O F S L A V E = 4
M A S T E R & S L A V E C O N T R O L = Y E S _
Figure 3-44
3. Press “ to confirm and the menu will automatically switch to the series/parallel
MASTER page as shown in Figure 3-45.
∑ V
= 6 0. 0 0 _
V I = 1 0.
0 0 A M S T O F F
0 .
0 0 0 0 V 0 .
0 0 0 0 A
0 . 0 W
Figure 3-45
4. The SLAVE page will automatically switch to Figure 3-46.
1
ENTER
