Program Sequence
4-13
[ S E Q U E N C E ]
S E Q N O = 1
S E Q T Y P E = M A N U A L _
V O L T A G E = 0 . 0 0 V
V
S . R . = 1 . 0 0 0 ( V/ m s )
C U R R E N T
= 0 . 0 0 0 A
I
S . R . = I N F . ( A / m s ) ▲
▼
Figure 4-12
c. Setting Sequence Type to TRIGGER
When SEQ TYPE = TRIGGER is set, the Sequence page shown in Figure 4-13
indicates the sequence will run automatically and stop at the VOLTAGE or
CURRENT setting without skipping to the next sequence until a signal is input from
PIN 8 of the Analog Interface on the rear panel (see section Error! Reference
source not found.
for the input signal definition of Analog Interface PIN 8). The
(TIME =) setting does not display when the Sequence Type is set to TRIGGER.
[ S E Q U E N C E ]
S E Q N O = 1
S E Q T Y P E = T R I G G E R _
V O L T A G E = 0 . 0 0 V
V
S . R . = 1 . 0 0 0 ( V/ m s )
C U R R E N T
= 0 . 0 0 0 A
I
S . R . = I N F . ( A / m s ) ▲
▼
Figure 4-13
d. Set Sequence Type to SKIP
When SEQ TYPE = SKIP is set, the Sequence page shown in Figure 4-14 indicates
the Sequence will skip automatically and jump to the next SEQUENCE. The
(TIME =) setting does not display when the Sequence Type is set to SKIP.
[ S E Q U E N C E
]
S E Q N O = 1
S E Q T Y P E =
S K I P _
V O L T A G E = 0 . 0 0 V
V
S . R . = 1 .
0 0 0 ( V/ m s )
C U R R E N T = 0 . 0 0 0
A
I S . R . = I N F . (
A / m s ) ▲
▼
Figure 4-14
