Chroma A620028 User Manual

Overview
1-3
Table 1-1 62000H Series with Solar Array Simulation Operating Specifications
Model
62020H-150S
62050H-600S
62100H-600S
62150H-600S
Output Ratings
Output Voltage
1
0-150V
0-600V
0-600V
0-600V
Output Current
2
0-40A 0-8.5A 0-17A 0-25A
Output Power
2000W
5000W
10000W
15000W
Voltage
Measurement
Range
3
60V / 150V
120V / 600V
120V / 600V
120V / 600V
Accuracy
0.05% +
0.05%F.S
0.05% +
0.05%F.S.
0.05% +
0.05%F.S.
0.05% +
0.05%F.S.
Current
Measurement
Range
3
16A / 40A
3.4A / 8.5A
6.8A / 17A
10A / 25A
Accuracy
0.1% +
0.1%F.S.
0.1% +
0.1%F.S.
0.1% +
0.1%F.S.
0.1% +
0.1%F.S.
Output Noise &
Ripple
Voltage
Noise(P-P)
4
450 mV 1500 mV 1500 mV 1500 mV
Voltage
Ripple(rms)
65 mV 650 mV 650 mV 650 mV
Current
Ripple(rms)
5
80 mA 150 mA 300 mA 450 mA
Programming
Response Time
Rise Time:
50%F.S. CC
Load
10ms
(6.66A loading)
30 ms 30 ms 30 ms
Rise Time: No
Load
10ms 30 ms 30 ms 30 ms
Fall Time:
50%F.S. CC
Load
10ms
(6.66A loading)
30 ms 30 ms 30 ms
Fall Time:
10%F.S. CC
Load
83ms
(1.33A loading)
100 ms 100 ms 100 ms
Fall Time:No
Load
300ms 1.2 s 1.2 s 1.2 s
Slew Rate
Control
Voltage slew
rate range
6
0.001V/ms -
15V/ms
0.001V/ms –
20V/ms
0.001V/ms –
20V/ms
0.001V/ms –
20V/ms
Current slew
rate range
7
0.001A/ms -
1A/ms, or INF
0.001A–
0.1A/ms or INF
0.001A–
0.1A/ms or INF
0.001A–
0.1A/ms or INF
Minimum
transition time
0.5ms 0.5 ms 0.5 ms 0.5 ms
