5.2.- ENERGY CLOSES MENU
The screen in Figure 87 is the home screen for the energy close menu.
Figure 87: Main screen of the energy closes menu.
In the information menu you can view:
The active energy closes III of the total tariff.
( “5.2.1 Active energy closes III of the total tariff and of reactive energy III of the
total tariff.)
The reactive energy closes III of the total tariff.
( “5.2.1 Active energy closes III of the total tariff and of reactive energy III of the
total tariff.)
Main menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
