10.4.- MODBUS TCP (Bridge) COMMUNICATIONS
General features
Maximum power of the module 2 W
Communications : Modbus TCP
Connector RJ-45
Protocol Modbus/TCP
Baud rate Ethernet 10BT / 100BT
Communications: RS-485 gateway
Bus RS-485
Protocol Modbus
Peripheral number 1 ... 255
Baud rate 9600 - 19200 - 38400 - 57600 - 76800 - 115200
Data bits 7- 8
Stop bits 1- 2
Parity No - even - odd
Environmental features
Operating temperature -10ºC ... +50ºC
Storage temperature -20ºC ... +80ºC
Relative humidity (without condensation) 5 ... 95%
Maximum altitude 2000 m
Protection degree
(1)
IP30
Mechanical features
Dimensions (mm) Figure 225 and Figure 226
Weight 80 g
Enclosure V0 self-extinguishing plastic
Assembly Panel
(1)
This pollution degree hasn’t been tested by UL.
Standards
Safety requirements for electrical equipment for measurement, control
and laboratory use
IEC 61010: 2010
Electromagnetic compatibility (CEM). Part 6-2: Generic standards. Immu-
nity for industrial environments.
UNE-EN 6100-6-2:2006
Electromagnetic compatibility (CEM). Part 6-4: Generic standards. Emis-
sions standard for industrial environments.
UNE-EN 6100-6-4:2007
Coordination of the insulation of units installed in low voltage systems
(networks)
IEC 664: 2007
Information technology equipment. Radio disturbance characteristics.
Limits and methods of measurement.
UNE-EN 55022
Safety requirements for electrical equipment for measurement, control,
and laboratory use - Part 1: General requirements
UL/CSA 61010-1 3rd edition
320
CVM-B100 - CVM-B150
Instruction Manual
