7.6.5.- LIST OF LONWORKS LOGS
Note: The binary les and setup le can be downloaded from Circutor’s website.
Variable Name Variable type Unit
Current L1
nvo_Ph1Current SNVT_amp_ac (139) A 1
Code Resolution Values
02 1 0..65,534
Current L2
Name Variable type Unit
nvo_Ph2Current SNVT_amp_ac (139) A 2
Code Resolution Values
07 1 0..65,534
Current L3
Name Variable type Unit
nvo_Ph3Current SNVT_amp_ac (139) A 3
Code Resolution Values
12 1 0..65,534
Phase-Phase Voltage V12
Name Variable type Unit
nvo_Ph2PhU12 SNVT_volt_ac (138) V 12
Code Resolution Values
22 1 0..65,534
Phase-Phase Voltage V23
Name Variable type Unit
nvo_Ph2PhU23 SNVT_volt_ac (138) V 23
Code Resolution Values
23 1 0..65,534
Phase-Phase Voltage V31
Name Variable type Unit
nvo_Ph2PhU31 SNVT_volt_ac (138) V 31
Code Resolution Values
24 1 0..65,534
Phase-Neutral Voltage L1
Name Variable type Unit
nvo_Ph2NU1 SNVT_volt_ac (138) V 1
Code Resolution Values
01 1 0..65,534
Phase-Neutral Voltage L2
Name Variable type Unit
nvo_Ph2NU2 SNVT_volt_ac (138) V 2
Code Resolution Values
06 1 0..65,534
Phase-Neutral Voltage L3
Name Variable type Unit
nvo_Ph2NU3 SNVT_volt_ac (138) V 3
Code Resolution Values
11 1 0..65,534
Frequency
Name Variable type Unit
nvo_Frequency SNVT_freq_hz (76) Hz
Code Resolution Values
21 0.1 0..6553.5
Active Power L1
Name Variable type Unit
nvo_ActPwrPh1 SNVT_power_kilo (28) kW L1
Code Resolution Values
03 0.1 0..6553.5
272
CVM-B100 - CVM-B150
Instruction Manual
