Next, selects the next parameter.
Confirm, confirms and saves in the memory the values programmed on the
screen
.
Back, returns to the home screen of the setup menu Figure 114.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
● To program the default screen :
Default, select the screen with the 4-parameter voltage measurement.
Customised 1 parameter, select the rst 1-parameter customisable screen.
Customised 3 parameter, select the rst 3-parameter customisable screen.
Customised 4 parameter, select the rst 4-parameter customisable screen.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the home screen of the setup menu Figure 114.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
5.6.21.- EXPANSION MODULES.
If expansion modules have been connected in the unit, the programming of the various modules
can be accessed via this menu. See “7.- EXPANSION MODULES”.
175
Instruction Manual
CVM-B100 - CVM-B150
