7.9.5.- MODBUS COMMUNICATIONS
The following functions are implemented for these variables:
Function 0x04: reading registers.
7.9.5.1.- TCP parameters
Table 156: Modbus memory map: : Datalogger module (Table 1)
TCP parameters
Configuration variable Address Valid data margin Example
DHCP Flag E2AE
0 : Deactivation
1: Activation
-
IP Address E290 - E291 1 long : 4 characters AC109C4B (172.16.156.75)
Subnet Mask E292 - E293 1 long : 4 characters FFFFF000 (255.255.240.0)
Gateway E294 - E295 1 long : 4 characters AC109601(172.16.150.1)
MAC E2A0 - E2A2 3 integers : 6 characters 14A62C001D54 (14.A6.2C.00.1D.54)
7.9.5.2.- Port address and versions
Table 157:Modbus memory map: : Datalogger module (Table 2)
Port address and versions
Configuration variable Address Valid data margin
Port E296 - E297 1 long
Embedded version E298 - E29B 4 integers : 8 characters
PowerStudio version E29C - E29F
4 integers : 8 characters
