Table 5 ( Continuation ): CVM-Bx measurement parameters.
Parameter Units
Phases
L1-L2-L3
N
Total
III
Maximum Apparent Power Demand, Tariff 1 kVA
 
Maximum Current Demand, Tariff 2 A
 
Maximum Active Power Demand, Tariff 2 kW
 
Maximum Apparent Power Demand, Tariff 2 kVA
 
Maximum Current Demand, Tariff 3 A
 
Maximum Active Power Demand, Tariff 3 kW
 
Maximum Apparent Power Demand, Tariff 3 kVA
 
Phase sequence

Parameter Units
Tariff:
T1-T2-T3
Total Tariff
No. of hours of active tariff hours
 
Cost COST
 
CO
2
Emissions kgCO
2
 
4.3.- KEYPAD FUNCTIONS
The CVM-B has 3 keys that allow you to browse the various screens and program the unit.
Table 6: Function of keys.
Key Keystroke
Shifting to the left
Shifting to the right
Select parameter / Enter programming menu
