Table 27 ( Continuation ) : Modbus memory map: Voltage and current harmonics.
Parameter Voltage L1 Voltage L2 Voltage L3 Neutral Voltage
Units
(1)
36th Order harmonic 1352 1386 13BA 13EE 1581
37th Order harmonic 1353 1387 13BB 13EF 1581
38th Order harmonic 1354 1388 13BC 13F0 1581
39th Order harmonic 1355 1389 13BD 13F1 1581
40th Order harmonic 1356 138A 13BE 13F2 1581
41st Order harmonic 1357 138B 13BF 13F3 1581
42nd Order harmonic 1358 138C 13C0 13F4 1581
43rd Order harmonic 1359 138D 13C1 13F5 1581
44th Order harmonic 135A 138E 13C2 13F6 1581
45th Order harmonic 135B 138F 13C3 13F7 1581
46th Order harmonic 135C 1390 13C4 13F8 1581
47th Order harmonic 135D 1391 13C5 13F9 1581
48th Order harmonic 135E 1392 13C6 13FA 1581
49th Order harmonic 135F 1393 13C7 13FB 1581
50th Order harmonic 1360 1394 13C8 13FC 1581
(1)
Format of the units: Power of 10 (with sign).
6.3.5.- COST VARIABLES
These parameters occupy 2 registers each.
Each unit occupies a separate register.
For these variables Function 0x04 is implemented: reading registers.
Table 28: Modbus memory map: cost variables
Parameter
Tariff 1 Tariff 2 Tariff 3 Total
Units
(1)
No. of active energy hours consumed LIII 15E0-15E1 15EC-15ED 15F8-15F9 1604-1605 1584
Cost of active energy consumed LIII 15E2-15E3 15EE-15EF 15FA-15FB 1606-1607 1586
Consumed CO
2
emissions 15E4-15E5 15F0-15F1 15FC-15FD 1608-1609 1585
No. of active energy hours generated LIII 15E6-15E7 15F2-15F3 15FE-15FF 160A-160B 1584
Cost of active energy generated LIII 15E8-15E9 15F4-15F5 1600-1601 160C-160D 1586
Generated CO
2
emissions 15EA-15EB 15F6-15F7 1602-1603 160E-160F 1585
(1)
Format of the units: Power of 10 (with sign).
6.3.6.- ANGLE VARIABLES
These parameters occupy 2 registers each.
For these variables Function 0x04 is implemented: reading registers.
Table 29:Modbus memory map: Angle variables.
Parameter Address Units
V1-V2 angle 1770-1771 Degrees x 1000 (with sign)
V2-V3 angle 1772-1773 Degrees x 1000 (with sign)
V3-V1 angle 1774-1775 Degrees x 1000 (with sign)
V1-I1 angle 1776-1777 Degrees x 1000 (with sign)
V2-I2 angle 1778-1779 Degrees x 1000 (with sign)
V3-I3 angle 177A-177B Degrees x 1000 (with sign)
187
Instruction Manual
CVM-B100 - CVM-B150
