Table 27 ( Continuation ) : Modbus memory map: Voltage and current harmonics.
Parameter Voltage L1 Voltage L2 Voltage L3 Neutral Voltage
Units
(1)
41st Order harmonic 1285 12B9 12ED 1321 1581
42nd Order harmonic 1286 12BA 12EE 1322 1581
43rd Order harmonic 1287 12BB 12EF 1323 1581
44th Order harmonic 1288 12BC 12F0 1324 1581
45th Order harmonic 1289 12BD 12F1 1325 1581
46th Order harmonic 128A 12BE 12F2 1326 1581
47th Order harmonic 128B 12BF 12F3 1327 1581
48th Order harmonic 128C 12C0 12F4 1328 1581
49th Order harmonic 128D 12C1 12F5 1329 1581
50th Order harmonic 128E 12C2 12F6 132A 1581
Parameter Current L1 Current L2 Current L3 Neutral Current
Units
(1)
Fundamental Harm. 132E – 132F 1362 – 1363 1396 – 1397 13CA – 13CB A x 1000
2nd Order harmonic 1330 1364 1398 13CC 1581
3rd Order harmonic 1331 1365 1399 13CD 1581
4th Order harmonic 1332 1366 139A 13CE 1581
5th Order harmonic 1333 1367 139B 13CF 1581
6th Order harmonic 1334 1368 139C 13D0 1581
7th Order harmonic 1335 1369 139D 13D1 1581
8th Order harmonic 1336 136A 139E 13D2 1581
9th Order harmonic 1337 136B 139F 13D3 1581
10th Order harmonic 1338 136C 13A0 13D4 1581
11th Order harmonic 1339 136D 13A1 13D5 1581
12th Order harmonic 133A 136E 13A2 13D6 1581
13th Order harmonic 133B 136F 13A3 13D7 1581
14th Order harmonic 133C 1370 13A4 13D8 1581
15th Order harmonic 133D 1371 13A5 13D9 1581
16th Order harmonic 133E 1372 13A6 13DA 1581
17th Order harmonic 133F 1373 13A7 13DB 1581
18th Order harmonic 1340 1374 13A8 13DC 1581
19th Order harmonic 1341 1375 13A9 13DD 1581
20th Order harmonic 1342 1376 13AA 13DE 1581
21st Order harmonic 1343 1377 13AB 13DF 1581
22nd Order harmonic 1344 1378 13AC 13E0 1581
23rd Order harmonic 1345 1379 13AD 13E1 1581
24th Order harmonic 1346 137A 13AE 13E2 1581
25th Order harmonic 1347 137B 13AF 13E3 1581
26th Order harmonic 1348 137C 13B0 13E4 1581
27th Order harmonic 1349 137D 13B1 13E5 1581
28th Order harmonic 134A 137E 13B2 13E6 1581
29th Order harmonic 134B 137F 13B3 13E7 1581
30th Order harmonic 134C 1380 13B4 13E8 1581
31st Order harmonic 134D 1381 13B5 13E9 1581
32nd Order harmonic 134E 1382 13B6 13EA 1581
33rd Order harmonic 134F 1383 13B7 13EB 1581
34th Order harmonic 1350 1384 13B8 13EC 1581
35th Order harmonic 1351 1385 13B9 13ED 1581
186
CVM-B100 - CVM-B150
Instruction Manual
